1990 Brett Linea alimentazione grosso spessore 650x7
1990 Brett Linea alimentazione grosso spessore 650x7
Location:Friuli-Venezia Giulia, Italy
Description
Line LInea of uncoiling and flattening of Coil width 650x7 thus composed:
single spooler piston? Wait: aspo svolgitore is winch? In machinery,
large 800 spindle
accessories:
mobile rotating loading saddle at 180°
Aspo con motorizzazione totalmente idraulica
hydraulic spindle expansion
double hydraulic actuator arm and motorized
straightener with head entry group of the roll
downward command for powered leveling rollers
hydraulic shear for head/tail clamping on the roll
Specifications
| Manufacturer | Brett |
| Model | Linea alimentazione grosso spessore 650x7 |
| Year | 1990 |
| Condition | Used |
| Stock Number | 649 |
| Feeding (compact direct/traditional feeder) | Traditional |
| Max width (mm) | 650 |
| Max thickness (mm) | 7 |
| Loading cradle | Se roto traslante |
| Max coil weight (ton) | 15 ton or double 10+10 ton |
| Unwinding reel - Max width (mm) | 800 |
| Decoiler - Max weight (tons) | 15 ton or double 10+10 ton |
| Unwinding reel - Hydraulic expansion | Yes |
| Unwinding reel - Pressing arm | Powered by guide cones |
| Straightener - Number of rollers | 9 |
| Straightener - roller diameter | 120 |
| Rectifier - Max thickness (mm) | 7 |
| Straightener - Max speed (m/min) | 40 |
| Straightener - Belt Lubrication System | No |
| Rectifier - Introducer | Yes |
