BLISS 200 ton
BLISS 200 ton
Location:Cumiana, Italy
Specifications
| Manufacturer | BLISS |
| Model | S 1-200 |
| Year | 1980 |
| Condition | Used |
| Stock Number | 369 |
| Ton | 200 |
| Frame (H/C) | H |
| Conditions | WORKING |
| Activation system (eccentric/link motion/knucle joint/oleodynamic/screw fly) | ECCENTRIC |
| Table - width (mm) | 1000 |
| Table - x (mm) | 1000 |
| Table - y (mm) | 800 |
| Slide - y (mm) | 800 |
| Slide - x (mm) | 800 |
| Slide - adjustable stroke (mm) | 100 |
| Piston rods | 1 |
| Number of strokes/minute | 30 |
| Tdc span (mm) | 600 |
| Lateral window (mm) | 200 |
| External dimensions - X (mm) | 2000 |
| Slide - stroke (mm) | 200 |
| Number of strokes / min | 30 |
| Subtype (DM / CDC) | DOUBLE UPRIGHT |
| Drive system (eccentric / link motion / knucle joint / hydraulic / screw fly) | ECCENTRIC |
| Table - depth (mm) | 800 |
| External dimensions - Y (mm) | 2000 |
| External dimensions - height (mm) | 4500 |
| Motor power (kW) | 20 |
| Electrical components - other infos | ACCORDING TO LAW REQUIREMENTS |
| Weight (ton) | 18 |
| Slide - width (mm) | 800 |
| Slide - depth (mm) | 800 |
| Push points | 1 |
| Light pms (mm) | 600 |
| Side window between the uprights (mm) | 200 |
| External dimensions - width (mm) | 2000 |
| External dimensions - depth (mm) | 2000 |
| External dimensions - height above ground (mm) | 4500 |
| Motor power (kw) | 20 |
| Electrical components - more info | IN STANDARDS |
